Renowned for their excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, Alloy 20 bolts are the preferred choice for demanding applications. Industries such as chemical, pharmaceutical, and food processing rely on their robust performance and durability.

Alloy 20 bolts are highly sought-after fasteners made from Alloy 20, a nickel-chromium-molybdenum stainless steel alloy. These bolts offer exceptional corrosion resistance in various environments, including sulfuric acid, chloride-containing solutions, and various corrosive substances.

Mechanically, Alloy 20 bolts offer impressive strength and toughness. They provide reliable and secure fastening solutions with a minimum tensile strength of 80 ksi (550 MPa) and a minimum yield strength of 35 ksi (240 MPa). Their ductility and resistance to deformation make them suitable for applications subjected to heavy loads and vibrations.

Alloy 20 Bolt
Table of Content

The unique composition of Alloy 20, which includes nickel, chromium, molybdenum, and copper, contributes to its remarkable corrosion resistance. Adding copper enhances its resistance to sulfuric acid and other reducing agents.

Look for a supplier with a proven track record, industry expertise, and stringent quality control processes. Timely delivery, competitive pricing, and excellent customer service should also be priorities.

Zeon Fasteners LLP is a rapidly expanding exporter and dealer of Alloy 20 bolts. As a subsidiary of the well-established Shanti Metal Syndicate, with over five decades of experience, we have inherited a legacy of excellence in the industry. Our expertise and commitment to delivering top-quality products have earned us the reputation of industry experts. We are dedicated to ensuring smooth business operations and providing our clients with products of the highest quality. Our client base spans the globe, reflecting our ability to serve diverse markets.

Nickel Alloy 20 Bolts Manufacturers, Alloy 20 Bolts, Alloy 20 Socket Head Bolts, ASTM B473 Inconel 20 Heavy Hex Bolts, Carpenter 20 Bolts, UNS N08020 Bolts, Type Incoloy® Alloy 20 Eye Bolts At Best Price In India, Nickel Alloy 20 Bolts, Alloy 2.4660 Bolts, Inconel 20 Bolts, Alloy 20 Bolts Supplier in Mumbai, India.

Alloy 20 Bolts

Specification For Alloy 20 Bolts

Standard: ASTM B473
Size : Cold Forming process: M2-M24 Hot Forging process: M24-M100, 1-1/2” Dia, up to 1100mm lg CNC Machining for M100 / 4” Dia, up to 1500mm lg Manufacturing M2, M3, M3.5, M4, M5, M6, M8, M10, M12, M14, M16, M18, M20, M22, M24, M27, M30, M33, M36, M42, M45, M48 to M160 and Custom Metric Hex Nuts
Nuts Size Metric: Dia: M10 – M110 / Length: 12 – 1200MM
Nuts Size Inch: Dia: 1/2″ – 4.0″ / Length: 1/2″ – 52″
Length: 3 to 200 mm
Standard: ISO, IS, ANSI, ASME, UNI, ASTM, DIN, JIS, IS, GB, BS, CSN, EU, IFI, PN, and all International Standards
DIN Standard : DIN 934, DIN 982, DIN 985, DIN 936, DIN 929, DIN 1587, DIN 439, DIN 315
Threads: METRIC, BSW, UNC, UNF, BSF or as required
Nuts Forming: Hot Forged Nuts & Cold Forged Nuts
UTS – Unified Thread Standard: UNC, UNF, NPT, UNS, UNEF, NPTF
ASME Standard: ASME B18.2.2 / ASME B18.16.6 /ASME B18.16.4 / ASME B18.2.2
Certification: Dual Certified As per ASTM & ASME Codes

Equivalent Grades Of Alloy 20 Bolts

STANDARD WERKSTOFF NR. UNS EN AFNOR
Alloy 20 2.4660 N08020 NiCr20CuMo Z2NCUD31-20AZ

ASTM B473 Alloy 20 Bolts Chemical Composition

Grade C Mn Si S Cu Ni Cr Fe Mo P
Alloy 20 0.07 max 2.00 max 1.00 max 0.035 max 3.00 – 4.00 32.00 – 38.00 19.00 – 21.00 29.85 min* 2.00 – 3.00 0.045 max

Alloy 20 Bolts Mechanical Properties

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Alloy 20 8.1 g/cm3 1443 °C (2430 °F) Psi -80,000, MPa -551 Psi – 35,000, MPa – 241 30 %

Alloy 20 Hex Bolts Dimension

NOMINAL SIZE (D) BODY DIAMETER HEAD THICKNESS ASTM B473 ACROASTM B473 THE FLATS ACROASTM B473 CORNERS
D (MAX) D (MIN) H (MAX) H (MIN) F (MAX) F (MIN) C (MAX) C (MIN)
m10 10.00 9.78 6.63 6.17 17.00 15.73 18.48 17.77
m12 12.00 11.73 7.76 4.24 19.00 17.73 20.78 20.03
m14 14.00 13.73 9.09 8.51 22.00 20.67 24.25 23.35
m16 16.00 15.73 10.32 9.68 24.00 23.67 27.71 26.75
m20 20.00 19.67 12.88 12.12 30.00 29.16 34.64 32.95
m24 24.00 23.67 15.44 14.56 36.00 35.00 41.57 39.55
m30 30.00 29.67 19.48 17.92 46.00 45.00 53.12 50.85
m36 36.00 35.61 23.38 21.63 55.00 53.80 63.51 60.79
m42 42.00 41.38 26.97 25.03 65.00 62.90 75.06 71.71
m48 48.00 47.38 31.07 28.93 75.00 72.60 86.60 82.76
m56 56.00 55.26 36.2 33.80 85.00 82.20 98.15 93.71
m64 64.00 63.26 41.32 38.68 95.00 91.80 109.70 104.65
m72 72.00 71.26 46.45 43.55 105.00 101.40 121.24 115.60
m80 80.00 79.26 51.58 48.42 115.00 111.00 132.72 126.54
m90 90.00 89.13 57.74 54.26 130.00 125.50 150.11 143.07
m100 90.00 99.13 63.9 60.10 145.00 140.00 167.43 159.60

Various Types of Alloy 20 Bolts

Alloy 20 Hex Bolts

Alloy 20 Hex Bolts

  • Nickel Alloy 20 Heavy Hex Bolt
  • ASTM B473 Alloy 20 Hex Bolts
  • Incoloy® Alloy 20 Hex Bolt
  • UNS N08020 Hex Bolts
  • Alloy 2.4660 Heavy Hex Bolt
  • Carpenter 20 Hex Bolts
  • Inconel 20 Heavy Hex Bolts
  • Alloy N08020 Hex Bolts
  • Alloy 20Cb-3® Heavy Hex Bolts
Alloy 20 Socket Head Bolts

Alloy 20 Socket Head Bolts

  • UNS N08020 Socket Head Bolts
  • Incoloy® Alloy 20 Socket Head Bolt
  • ASTM B473 Alloy 20 Socket Head Bolts
  • Nickel Alloy 20 Socket Head Bolt
  • Alloy 20Cb-3® Hex Socket Head Bolts
  • Alloy 2.4660 Socket Head Bolt
  • Alloy N08020 Socket Head Bolts
  • Carpenter 20 Socket Head Bolts
Alloy 20 Hex Flange Bolts

Alloy 20 Hex Flange Bolts

  • Incoloy® Alloy 20 Hex Flange Bolt
  • Carpenter 20 Hex Flange Bolts
  • ASTM B473 Carpenter 20 Hex Flange Bolts
  • Alloy 20 Hex Hex Flange Bolts
  • Alloy 2.4660 Hex Flange Bolt
  • Alloy 20Cb-3® Hex Flange Bolts
  • Alloy N08020 Hex Flange Bolts
  • Nickel Alloy 20 Hex Flange Bolt
  • UNS N08020 Hex Flange Bolts
Alloy 20 Eye Bolts

Alloy 20 Eye Bolts

  • Alloy N08020 Pigtail Eye Bolts
  • ASTM B473 Carpenter 20 Eye Bolts
  • Inconel 20 Eye Bolts
  • Incoloy® Alloy 20 Eye Bolt
  • UNS N08020 Eye Bolts
  • Alloy 2.4660 Anchor Eye bolts
  • Nickel Alloy 20 Eye Bolt
  • Alloy 20 Lifting Eye Bolt
  • Alloy 20Cb-3® Hex Eye Bolts
Alloy 20 U Bolts

Alloy 20 U Bolts

  • Alloy 20 U-Shaped Bolts
  • Nickel Alloy 20 U Bolt
  • Inconel 20 U Bolts
  • Alloy 20Cb-3® Square U Bolts
  • Alloy 20 Round Bend U-Bolts
  • Incoloy® Alloy 20 U Bolt
  • Alloy N08020 U-Bolts
  • Alloy 2.4660 Anchor U Bolts
  • UNS N08020 U Bolts
  • ASTM B473 Carpenter 20 U Bolts
Alloy 20 Carriage Bolts

Alloy 20 Carriage Bolts

  • Alloy N08020 Carriage Bolts
  • Alloy 2.4660 Carriage Bolts
  • Alloy 20 Round Neck Carriage Bolts
  • ASTM B473 Alloy 20Cb-3® Carriage Bolts
  • Incoloy® Alloy 20 Carriage Bolt
  • Alloy 20 Carriage Bolts Sizes Chart
  • UNS N08020 Carriage Bolts
  • Inconel 20 Carriage Bolts
  • Nickel Alloy 20 Carriage Bolt

Contact us to get a quick quote for your requirement.

We offer These Alloy 20 Bolts as per DIN, ISO, JIS or ANSI Standard.
