As the name implies, Super Duplex is a premium metal utilized in a variety of sectors to produce threaded rods, tubes, flanges, forgings, fittings, and other raw materials. Formic, acetic, and other organic acids are very resistant to super duplex steel. The high molybdenum and chromium level of its ingredients contribute to its resilience. It meets the needs of resistance to inorganic acids as well as organic acids, particularly those with a high chloride content. The chemical composition of Super Duplex and Duplex steels is the same, but what separates these two metals is the increased concentration of chemicals in Super Duplex steels, which further strengthens their corrosion resistance.

SDSS Threaded Rod
Table of Content

SDSS Threaded Rods, Super Duplex Stainless Steel Threaded Rods, Type Super Duplex Threaded Rods At Best Price In India, Super Duplex Steel Threaded Bars, Super Duplex Steel Threaded Rod, Ped Approved Manufacturer of Super Duplex Steel Threaded Rods, SDSS Partially Threaded Rods, Super Duplex Fully Threaded Rods Manufacturers, Super Duplex Steel Threaded Rods Supplier in Mumbai, India.

Super Duplex steel threaded rods are far more resistant to harsh industrial environments than duplex steel. Due to the high nickel content, it is more expensive than Duplex steel threaded rods. Welded threaded rods made of super duplex steel are utilized in applications that call for exceptional strength. While Super Duplex square threaded rods are very resistant to intergranular corrosion, Super Duplex round threaded rods exhibits superior properties when compared to Grade 316 steel in practically all types of media. Ferritic and austenitic characteristics can be found in Super Duplex threaded rods. The pharmaceutical industry, pulp, and paper industry, petrochemical industry, specialty chemical industry, heat exchangers, condensers, power generation, gas processing, and offshore oil drilling companies are just a few industries that use super duplex steel threaded rods.

Zeon Fasteners LLP is an exporter and supplier of Super Duplex Steel Threaded Rods. We are Mumba-based distributors and stockists of various industrial materials. All of the products and services we provide are carefully inspected and of the highest quality. Our various services include complete pipeline solutions and quality tests. Currently, We have a capacity of 500 tonnes of storage at any given point.

SDSS Threaded Rods

Specification For SDSS Threaded Rods

Standard: ASTM F593
Dimension : ASTM, DIN, BS, GB, IS and all International Standards
Size : M6 to M52 & 1/4" to 2"
Dimensions : ASME B18.31.3, ASME B18.31.4M
Length : 1000mm to 3000mm & 1feet to 12 feet
Standard : DIN 975 or DIN 976, DIN 938
Unified Thread Standard (UTS): UNC, UNF, NPT, UNS, UNEF, NPTF
Threads Configuration : B1.13M 6h Metric Coarse Threads and ASME B1.1 2A/3A Inch Unified Threads
Stud Bolts Forming: Hot Forged Threaded Rods & Cold Forged Threaded Rods
Certification: Dual Certified As per ASTM & ASME Codes
Finish: Zinc Plated, Plain, Hot Dip Galv. & Yellow Zinc

Dimensions Chart of Super Duplex Steel Threaded Rods

Size (MM) Weight per Meter Size (UNC) Weight per Mtr
M2 0.0187
M2.5 0.030
M3 0.044
M3.5 0.060
M4 0.078
M5 0.124
M6 0.177 ¼” 0.194
M8 0.319 5/16” 0.323
M10 0.500 3/8” 0.469
    7/16” 0.650
M12 0.725 ½” 0.896
M14 0.970 9/16” 1.096
M16 1.330 5/8” 1.342
M18 1.650
M20 2.080 ¾” 2.021
M22 2.540 7/8” 2.756
M24 3.000 1” 3.638
M27 3.850 1 1/8” 4.545
M30 4.750 1 ¼” 5.718
M33 5.900 1 3/8” 6.842
M36 6.900 1 ½” 8.281
M39 8.200 1 5/8” 9.726
M42 9.400 1 ¾” 11.231
M45 11.000 1 7/8” 13.038
M48 12.400 2 14.741

LENGTH Diameter
1/2" 5/8" 3/4" 7/8" 1" 1.1/8" 1.1/4" 1.3/8" 1.1/2" 1.5/8" 1.3/4" 1.7/8" 2"
50 mm 0.044 0.069 0.100 0.136 0.178 0.225 0.296 0.356 0.422 0.493 0.570 0.681 0.771
55 mm 0.049 0.076 0.110 0.150 0.195 0.247 0.326 0.392 0.464 0.543 0.627 0.749 0.848
60 mm 0.053 0.083 0.120 0.163 0.213 0.270 0.355 0.428 0.506 0.592 0.684 0.817 0.925
65 mm 0.058 0.090 0.130 0.177 0.231 0.292 0.385 0.463 0.549 0.641 0.741 0.885 1.002
70 mm 0.062 0.097 0.140 0.190 0.249 0.315 0.415 0.499 0.591 0.690 0.798 0.953 1.079
75 mm 0.067 0.104 0.150 0.204 0.266 0.337 0.444 0.535 0.633 0.740 0.855 1.021 1.156
80 mm 0.071 0.111 0.160 0.218 0.284 0.360 0.474 0.570 0.675 0.789 0.912 1.089 1.233
85 mm 0.075 0.118 0.170 0.231 0.302 0.382 0.504 0.606 0.717 0.838 0.969 1.158 1.310
90 mm 0.080 0.125 0.180 0.245 0.320 0.404 0.533 0.641 0.760 0.888 1.026 1.226 1.387
95 mm 0.084 0.132 0.190 0.258 0.337 0.427 0.563 0.677 0.802 0.937 1.083 1.294 1.464
100 mm 0.089 0.139 0.200 0.272 0.355 0.449 0.592 0.713 0.844 0.986 1.140 1.362 1.541
110 mm 0.098 0.153 0.220 0.299 0.391 0.494 0.652 0.784 0.928 1.085 1.254 1.498 1.695
120 mm 0.107 0.166 0.240 0.326 0.426 0.539 0.711 0.855 1.013 1.184 1.388 1.634 1.850
125 mm 0.111 0.173 0.250 0.340 0.444 0.562 0.741 0.891 1.055 1.233 1.425 1.702 1.927
130 mm 0.115 0.180 0.260 0.353 0.462 0.584 0.770 0.926 1.097 1.282 1.482 1.770 2.004
140 mm 0.124 0.194 0.280 0.381 0.497 0.628 0.829 0.998 1.182 1.381 1.596 1.907 2.158
150 mm 0.133 0.208 0.300 0.408 0.533 0.674 0.889 1.069 1.266 1.480 1.710 2.043 2.312
160 mm 0.142 0.222 0.320 0.435 0.568 0.719 0.948 1.140 1.350 1.578 1.824 2.179 2.466
170 mm 0.151 0.236 0.340 0.462 0.604 0.764 1.007 1.212 1.435 1.677 1.938 2.315 2.620
175 mm 0.155 0.243 0.350 0.476 0.621 0.786 1.037 1.247 1.477 1.726 1.995 2.383 2.697
180 mm 0.160 0.250 0.360 0.489 0.639 0.809 1.066 1.283 1.519 1.776 2.052 2.451 2.774
190 mm 0.169 0.264 0.380 0.517 0.675 0.854 1.126 1.354 1.604 1.874 2.166 2.588 2.928
200 mm 0.178 0.277 0.399 0.544 0.710 0.899 1.185 1.425 1.688 1.973 2.280 2.724 3.083
210 mm 0.186 0.291 0.419 0.571 0.746 0.944 1.244 1.497 1.772 2.071 2.394 2.860 3.237
220 mm 0.195 0.305 0.439 0.596 0.781 0.989 1.303 1.568 1.857 2.170 2.508 2.996 3.391
225 mm 0.200 0.312 0.449 0.612 0.799 1.011 1.333 1.604 1.899 2.219 2.565 3.064 3.468
230 mm 0.204 0.319 0.459 0.625 0.817 1.034 1.363 1.639 1.941 2.269 2.622 3.132 3.545
240 mm 0.213 0.333 0.479 0.653 0.852 1.079 1.422 1.710 2.026 2.367 2.736 3.268 3.699
250 mm 0.222 0.347 0.499 0.680 0.888 1.124 1.481 1.782 2.110 2.466 2.850 3.405 3.853
260 mm 0.231 0.361 0.519 0.707 0.923 1.169 1.540 1.853 2.194 2.565 2.964 3.541 4.007
270 mm 0.240 0.375 0.539 0.734 0.959 1.213 1.600 1.924 2.279 2.663 3.078 3.677 4.161
275 mm 0.244 0.382 0.549 0.748 0.977 1.236 1.629 1.960 2.321 2.713 3.135 3.745 4.238
280 mm 0.249 0.388 0.559 0.761 0.994 1.258 1.659 1.995 2.363 2.762 3.192 3.813 4.316
290 mm 0.257 0.402 0.579 0.788 1.030 1.303 1.718 2.067 2.448 2.861 3.306 3.949 4.470
300 mm 0.266 0.416 0.599 0.816 1.065 1.348 1.777 2.138 2.532 2.959 3.420 4.086 4.624

Dimension Standard of Super Duplex Steel Double Ended Threaded Rods

Thread d (M27) M30 (M33) M36 (M39) M42 (M45) M48 (M52)
  (M27x2) M30x2 (M33x2) M36x3 (M39x3) M42x3 (M45x3) M48x3 (M52x3)
b1 35 38 42 45 50 52 58 60 65
b2 l<125mm 60 66 72 78 84 90 96 102 110
b2 125>l<200mm 66 72 78 84 90 96 102 108 116
b2 l>200mm 79 85 91 97 103 109 115 121 129
x1 7,5 9 9 10 10 11 11 12,5 12,5
x2 3,8 4,5 4,5 5 5 5,5 5,5 6,3 6,3
l js 15 Weight (7,85/dm3) per 1000 units, in
  kg
50
55
60
70
75 430
80 452
85 475 591
90 497 619 776
95 520 646 810
100 542 674 843 1011
110 587 730 910 1091 1326
120 632 785 977 1171 1420 1647 1963
130 677 841 1045 1251 1514 1756 2088 2364
140 722 896 1112 1331 1607 1865 2213 2506 3027
150 767 952 1179 1411 1701 1973 2338 2648 3794
160 812 1007 1246 1490 1795 2082 2462 2790 3360
170 857 1062 1313 1570 1889 2191 2587 2932 3527
180 902 1118 1380 1650 1982 2300 2712 3074 3694
190 947 1173 1447 1730 2076 2408 2837 3216 3861
200 992 1229 1515 1810 2170 2517 2962 3358 4027
220 1082 1340 1649 1970 2358 2735 3211 3642 4361
240 1172 1450 1784 2130 2545 2952 3461 3927 4694
260 1262 1562 1918 2289 2733 3170 3711 4211 5028
280 1352 1672 2052 2449 2920 3387 3961 4495 5361
300   1784 2186 2609 3108 3605 4210 4779 5694
320     2321 2769 3295 3822 4460 5063 6028
340     2455 2929 3483 4040 4710 5347 6361
360       3088 3670 4257 4959 5631 6695
380         3858 4475 5209 5915 7028
400         4045 4692 5459 6199 7362

d M 5 M 6 M 8 M 10 M 12 M 16 M 20 M 24
b1 10 12 16 20 24 32 40 48
b2 16 18 22 26 30 38 46 54

Super Duplex Steel S32205 Double Ended Threaded Rods Size Chart

3/8″-16 x 1-1/2″ 3/8″-16 x 1-1/4″ 3/4″-10 x 3″
1/2″-13 x 3″ 1/2″-13 x 2-1/2″ 5/16″-18 x 1″
3/8″-16 x 1″ 5/8″-11 x 3″ 3/8″-16 x 3/4″
1/2″-13 x 1-1/2″ 1/2″-13 x 2″ 5/16″-18 x 1-1/4″
1/4″-20 x 1″ 3/8″-16 x 2″ 5/8″-11 x 4″
5/8″-11 x 2-1/2″ 3/8″-16 x 2-1/2″ 3/8″-16 x 3″
1/2″-13 x 1-1/4″ 3/4″-10 x 2-1/2″

Various Types of Super Duplex Steel Threaded Rods

Super Duplex Steel Full Threaded Rods

Super Duplex Steel Full Threaded Rod

  • Super Duplex Stainless Steel Full Threaded Rods
  • SDSS Full Threaded Rods
  • Super Duplex Steel Full Threaded Rods
  • Super Duplex Full Threaded Rods
  • Super Duplex Steel Fully Threaded Bars
  • Super Duplex Fully Threaded Rod
Super Duplex Steel Double Ended Threaded Rods

Super Duplex Steel Double Ended Threaded Rod

  • Super Duplex Stainless Steel Double Ended Threaded Rods
  • Super Duplex Double-End Threaded Bars
  • SDSS Double Ended Threaded Rods
  • Super Duplex Steel Double End Threaded Bar
  • SDSS Double Ended Threaded Rods
Super Duplex Steel Partially Threaded Rods

Super Duplex Steel Partially Threaded Rod

  • Super Duplex Steel Partially Threaded Rods
  • Super Duplex Partially Threaded Rods
  • SDSS Partially Threaded Rods
  • Super Duplex Stainless Steel Partially Threaded Rods

Contact us to get a quick quote for your requirement.

We offer These Super Duplex Steel Threaded Rods as per DIN, ISO, JIS or ANSI Standard.

Contact Us

info@zeonfasteners.com

Call us

+91 80 8218 7464

Request a Quote

Ready Stock Of Super Duplex Steel Threaded Rods

  • Super Duplex Steel Metric Threaded Rods
  • SDSS Threaded Bars
  • Super Duplex Steel Threaded Rods
  • Super Duplex Steel Full Thread Rods
  • Super Duplex Partially Threaded Rod
  • Super Duplex Steel Threaded Rods Weight Chart
  • SDSS Threaded Rod Sized in Inches
  • Type of Super Duplex Steel Threaded Bars
  • Super Duplex Double End Threaded Rods
  • Super Duplex Steel Threaded Rods

SDSS Threaded Rods Applications and Uses

We Serve Application Industry

Chemical Industry
Petrochemical Industry
Oil & Gas Industry
Marine Industry
Power Generation Industry
Sugar Industry
Marine Industry
Pharmaceuticals Industry
Cement Industry
Dairy Industry
Food Processing Industry
Paper & Pulp Industry
Offshore & Onshore Services

Chemical Industry Oil and Gas Industry Petrochemical Industry Power Generation Industry Cement Industry Food Processing Industry
